Luxury houses and energy efficient buildings need to be insulated from the floor up to really perform and if underfloor heating is going to be installed then underslab insulation is mandatory.
Board Thicknesses: 30mm, 40mm & 50mm: Order per m2 online.
Our SANBOARD 30mm, 40mm & 50mm XPS Floor Insulation Boards are the highest density (35 - 37kg/m3) extruded polystyrene insulation boards in South Afrcia making them stand out clearly against competitiors offerings to architects, engineers and home owners.
Having a board density of 35 - 37kg/m3 means our boards:
✔ Compressive strength is 310 - 360 kPa vs 160 - 310 kPa (Competitors)
✔ Water absorbtion is <0.5 % by volume vs <1.0% (Competitors)
✔ Are significantly stronger boards and will last longer
✔ Absorb significantly less water which affects thermal insulation
In simple terms, with a current fire rating of B-s1, d1, in accordance with SANS 53501-1 and such a high density, they better designed than competitors boards for underslab insulation applications.
Without insulation under the slab:
- Floors feel cold all year round
- Heat disappears into the ground
- Energy costs increase
With SANBOARD XPS Floor Insulation Boards:
- Floors stay warmer and more comfortable
- Heat stays inside the home
- Lower long-term electricity costs
Order direct, nationally online:
✔ We sell directly to the public (online)
✔ Request a quote for contractor or bulk orders.
This is not a retrofit product:
✔ 70% of homeowners wish they installed this product when the first winter came
✔ Your can not retrofit this product. It must be placed before the floor slab is cast
✔ With underfloor heating you need to meet insulation building regulations
Fast national availability and delivery:
✔ Order lead time is generally 3 to 5 working days
✔ We delivery everywhere in South Africa & Export
✔ We have very competitive delivery fees
Aged material thermal values (R-Value)
✔ 30mm | 1.00 m2.K/W
✔ 40mm | 1.333 m2.K/W
✔ 50mm | 1.667 m2.K/W
Easy to install:
✔ Build the foundations
✔ Compact the soil
✔ Add your DPC plastic sheeting
✔Tightly lay the polystyrene
✔ Add you spacers and mesh
✔ Cast the concrete slab
Order your floor and wall insulation boards at the same time. They go in very fast.
SANBOARD™ (XPS) Concrete Floor Insulation Boards – ISO, SANS 10400-XA, Compliant
Property Specification Material Type Extruded Polystyrene (XPS) Unique Feature Highest-density XPS ceiling board in South Africa Density 35–37 kg/m³ Compressive Strength 310–360 kPa Water Absorption 0.5% by volume Thermal Conductivity (k-value) Thermal Conductivity (k-value) Dimensional Stability < 1.0% Linear Thermal Expansion 0.049 mm/m/°C Combustibility / Flame Spread B/B1/2/H&V/B - S1, D1 (SANS 53501-1) Width 600mm Thicknesses 30mm. 40mm & 50mm Lengths 1800mm - 8000mm Paint Compatibility Water-based acrylic or PVA recommended
